Bring Disc Playback Into the Present with DM15 R2R, Featuring Modern Connectivity, an R2R DAC, and Warm Sound You Can Take Anywhere

• Features FiiO developed R2R DAC
• Up to 1150mW + 1150mW output in desktop mode
• Bluetooth transmit mode with aptX, aptX-HD, aptX-LL, aptX-Adaptive

• Anti-vibration support
• 3.5mm and 4.4mm outputs


On-the-Go

The DM15 R2R delivers a compact footprint, modern connectivity, and an R2R DAC that gives your CDs a warm, textured sound you can take anywhere. It runs on a high-voltage lithium battery, delivers both single-ended and fully-balanced outputs, and supports USB DAC, Bluetooth transmit, and optical/coaxial output modes. Whether you’re listening at your desk or unwinding on the couch, the DM15R2R keeps your discs in rotation without tying you to a wall outlet.

Proprietary R2R DAC

At the heart of the DM15 R2R is FiiO’s self-developed R2R DAC. It uses a resistor ladder to convert digital data into analog waveforms. That translates to a smoother, more organic style of playback many listeners prefer. The player also delivers low noise and distortion—THD+N under 0.030% at 1kHz, and a signal-to-noise ratio of at least 112dB—so quiet passages stay quiet and dynamic passages stay bold.

Bluetooth Connectivity

If you want to step away from cables, the DM15 R2R can transmit Bluetooth to your favorite wireless headphones or speakers. Supported codecs include SBC, aptX, aptX-HD, aptX-LL, and aptX-Adaptive. It’s a simple way to listen to your discs without being anchored to a cord.

Anti-Vibration Support

The ESP switch stabilizes playback when the player moves or shifts. It reduces the chance of skipping while walking or carrying the unit from room to room. Once you’re settled at your desk or on the couch, you can leave it on or off. The player handles disc reading reliably either way.

Specifications

• Operating Modes: CD play / USB DAC / Bluetooth transmit / Optical out / Coaxial out

• Headphone Outputs: 3.5mm single-ended, 4.4mm balanced

• Line Outputs: 3.5mm LO/COAX/OPT (3-in-1), 4.4mm balanced LO

• Supported CD-R Formats: FLAC, WAV, WMA, AAC, MP3

• DAC: FiiO self-developed R2R DAC

• Amplifier: SGM8262 × 2

• Bluetooth Chip: QCC3095

• USB Chip: SPV5048

• Display: 0.96-inch LCD

• Battery Capacity: 4700mAh

• Battery Life: ≥7 hours

• Rated Input: 5V 2A (USB-C)

• Charging: Supports PD2.0 and PD3.0 fast charging

• Charging Time: ~2 hours (PD3.0)

• USB DAC: 384kHz/32bit, DSD256 (Native)

• Coaxial Output: 192kHz/24bit

• Optical Output: 96kHz/24bit
• Weight: 1.04lbs
• Dimensions: 5.67" x 5.39" x 1"

In the Box

• FiiO DM15 R2R CD player
• Infrared remote (does not include button cell battery)
• USB-A to USB-C charging/data cable
• Quickstart guide
• 3.5mm coax adapter cable
